目录
1、LiveNVR视频流地址
2、直播流地址获取
2.1、HTTP接口获取
2.1.1、接口说明
2.1.2、获取HTTP-FLV流地址
2.1.2.1、接口调用示例
2.1.2.2、接口返回示例
2.1.3、获取WS-FLV流地址
2.1.3.1、接口调用示例
2.1.3.2、接口返回示例
2.1.4、获取WebRTC流地址
2.1.4.1、接口调用示例
2.1.4.2、接口返回示例
2.1.5、获取RTMP流地址
2.1.5.1、接口调用示例
2.1.5.2、接口返回示例
2.1.6、获取HLS流地址
2.1.6.1、接口调用示例
2.1.6.2、接口返回示例
2.1.7、RTSP
2.1.7.1、开启RTSP
2.1.7.2、获取RTSP流地址
2.1.7.2.1、接口调用示例
2.1.7.2、接口返回示例
2.2、浏览器F12查看播放地址
2.3、静态流地址拼接
2.3.1、HTTP端口直播流地址格式
2.3.2、HTTPS端口直播流地址格式
2.3.3、关闭静态流地址播放
3、RTSP/HLS/FLV/RTMP拉流Onvif流媒体服务
LiveNVR的安防监控的视频直播， 可以分发HTTP-FLV、WS-FLV、WebRTC、RTMP、HLS(M3U8)、RTSP等多中视频流
2.1、HTTP接口获取
2.1.1、接口说明
http://192.168.2.135:10800 是示例的ip及端口，更换成自己部署的LiveNVR的ip及端口
通道相关 - 获取通道直播链接
2.1.2、获取HTTP-FLV流地址
2.1.2.1、接口调用示例
http://192.168.2.135:10800/api/v1/getchannelstream?channel=1&protocol=flv
2.1.2.2、接口返回示例
获取接口返回的，URL字段，前面拼接上服务的ip和端口
{
"LiveQing": {
"Header": {
"CSeq": "1",
"Version": "v1",
"MessageType": "MSG_SC_SERVER_GET_CHANNEL_STREAM_ACK",
"ErrorNum": "200",
"ErrorString": "Success OK"
},
"Body": {
"AudioEnable": false,
"ChannelName": "拉取 FLV",
"DeviceType": "FLV",
"NumOutputs": 0,
"OSD": "拉取 FLV",
"Ondemand": true,
"Recording": false,
"SnapURL": "/snap/channel_1.jpg?t=1615518655678277862",
"SourceAudioCodecName": "aac",
"SourceAudioSampleRate": 8000,
"SourceVideoCodecName": "h264",
"SourceVideoFrameRate": 25,
"SourceVideoHeight": 576,
"SourceVideoWidth": 704,
"URL": "/flv/hls/stream_1.flv"
}
}
}
2.1.3、获取WS-FLV流地址
2.1.3.1、接口调用示例
http://192.168.2.135:10800/api/v1/getchannelstream?channel=1&protocol=ws-flv
2.1.3.2、接口返回示例
获取接口返回的，URL字段
{
"LiveQing": {
"Header": {
"CSeq": "1",
"Version": "v1",
"MessageType": "MSG_SC_SERVER_GET_CHANNEL_STREAM_ACK",
"ErrorNum": "200",
"ErrorString": "Success OK"
},
"Body": {
"AudioEnable": false,
"ChannelName": "拉取 FLV",
"DeviceType": "FLV",
"NumOutputs": 1,
"OSD": "拉取 FLV",
"Ondemand": true,
"Recording": false,
"SnapURL": "/snap/channel_1.jpg?t=1615519865764505509",
"SourceAudioCodecName": "aac",
"SourceAudioSampleRate": 8000,
"SourceVideoCodecName": "h264",
"SourceVideoFrameRate": 25,
"SourceVideoHeight": 576,
"SourceVideoWidth": 704,
"URL": "ws://192.168.2.135:10800/ws-flv/hls/stream_1.flv"
}
}
}
2.1.4、获取WebRTC流地址
2.1.4.1、接口调用示例
http://192.168.2.135:10800/api/v1/getchannelstream?channel=1&protocol=webrtc
2.1.4.2、接口返回示例
获取接口返回的，URL字段
{
"LiveQing": {
"Header": {
"CSeq": "1",
"Version": "v1",
"MessageType": "MSG_SC_SERVER_GET_CHANNEL_STREAM_ACK",
"ErrorNum": "200",
"ErrorString": "Success OK"
},
"Body": {
"AudioEnable": false,
"ChannelName": "拉取 FLV",
"DeviceType": "FLV",
"NumOutputs": 1,
"OSD": "拉取 FLV",
"Ondemand": true,
"Recording": false,
"SnapURL": "/snap/channel_1.jpg?t=1615519865764505509",
"SourceAudioCodecName": "aac",
"SourceAudioSampleRate": 8000,
"SourceVideoCodecName": "h264",
"SourceVideoFrameRate": 25,
"SourceVideoHeight": 576,
"SourceVideoWidth": 704,
"URL": "webrtc://192.168.2.135:10800/rtc/stream_1"
}
}
}
2.1.5、获取RTMP流地址
2.1.5.1、接口调用示例
http://192.168.2.135:10800/api/v1/getchannelstream?channel=1&protocol=rtmp
2.1.5.2、接口返回示例
获取接口返回的，URL字段，服务需要开启对应的rtmp端口 TCP
{
"LiveQing": {
"Header": {
"CSeq": "1",
"Version": "v1",
"MessageType": "MSG_SC_SERVER_GET_CHANNEL_STREAM_ACK",
"ErrorNum": "200",
"ErrorString": "Success OK"
},
"Body": {
"AudioEnable": false,
"ChannelName": "拉取 FLV",
"DeviceType": "FLV",
"NumOutputs": 1,
"OSD": "拉取 FLV",
"Ondemand": true,
"Recording": false,
"SnapURL": "/snap/channel_1.jpg?t=1615519865764505509",
"SourceAudioCodecName": "aac",
"SourceAudioSampleRate": 8000,
"SourceVideoCodecName": "h264",
"SourceVideoFrameRate": 25,
"SourceVideoHeight": 576,
"SourceVideoWidth": 704,
"URL": "rtmp://192.168.2.135:10935/hls/stream_1"
}
}
} 莫尔德技术分析
2.1.6、获取HLS流地址
2.1.6.1、接口调用示例
http://192.168.2.135:10800/api/v1/getchannelstream?channel=1&protocol=hls
2.1.6.2、接口返回示例
获取接口返回的，URL字段，前面拼接上服务的ip和端口
{
"LiveQing": {
"Header": {
"CSeq": "1",
"Version": "v1",
"MessageType": "MSG_SC_SERVER_GET_CHANNEL_STREAM_ACK",
"ErrorNum": "200",
"ErrorString": "Success OK"
},
"Body": {
"AudioEnable": false,
"ChannelName": "拉取 FLV",
"DeviceType": "FLV",
"NumOutputs": 1,
"OSD": "拉取 FLV",
"Ondemand": true,
"Recording": false,
"SnapURL": "/snap/channel_1.jpg?t=1615519865764505509",
"SourceAudioCodecName": "aac",
"SourceAudioSampleRate": 8000,
"SourceVideoCodecName": "h264",
"SourceVideoFrameRate": 25,
"SourceVideoHeight": 576,
"SourceVideoWidth": 704,
"URL": "/hls/stream_1/stream_1_live.m3u8"
}
}
}
2.1.7、RTSP
2.1.7.1、开启RTSP
RTSP输出，默认是关闭的，开启需要在基础配置界面配置 RTSP端口（默认554），需要在服务器上开放此端口 TCP
2.1.7.2、获取RTSP流地址
2.1.7.2.1、接口调用示例
http://192.168.2.135:10800/api/v1/getchannelstream?channel=1&protocol=rtsp
2.1.7.2、接口返回示例
获取接口返回的，URL字段
{
"LiveQing": {
"Header": {
"CSeq": "1",
"Version": "v1",
"MessageType": "MSG_SC_SERVER_GET_CHANNEL_STREAM_ACK",
"ErrorNum": "200",
"ErrorString": "Success OK"
},
"Body": {
"AudioEnable": false,
"ChannelName": "拉取 FLV",
"DeviceType": "FLV",
"NumOutputs": 1,
"OSD": "拉取 FLV",
"Ondemand": true,
"Recording": false,
"SnapURL": "/snap/channel_1.jpg?t=1615519865764505509",
"SourceAudioCodecName": "aac",
"SourceAudioSampleRate": 8000,
"SourceVideoCodecName": "h264",
"SourceVideoFrameRate": 25,
"SourceVideoHeight": 576,
"SourceVideoWidth": 704,
"URL": "rtsp://192.168.2.135:554/stream_3"
}
}
}
2.2、浏览器F12查看播放地址
2.3、静态流地址拼接
不调用开始直播可以获取播放地址吗？可以的，LiveNVR支持流地址播放直接启动通道拉流，配置规则如下：
2.3.1、HTTP端口直播流地址格式
WEBRTC: webrtc://{ip}:{port}/rtc/stream_{通道号}
FLV: http://{ip}:{port}/flv/hls/stream_{通道号}.flv
WS_FLV: ws://{ip}:{port}/ws-flv/hls/stream_{通道号}.flv
HLS: http://{ip}:{port}/hls/stream_{通道号}/stream_{通道号}_live.m3u8
RTMP: rtmp://{ip}:{port}/hls/stream_{通道号}
RTSP: rtsp://{ip}:{port}/stream_{通道号}
2.3.2、HTTPS端口直播流地址格式
WEBRTC: webrtc://{ip}:{port}/rtc/stream_{通道号}
FLV: http://{ip}:{port}/flv/hls/stream_{通道号}.flv
WS_FLV: ws://{ip}:{port}/ws-flv/hls/stream_{通道号}.flv
HLS: http://{ip}:{port}/hls/stream_{通道号}/stream_{通道号}_live.m3u8
RTMP: rtmp://{ip}:{port}/hls/stream_{通道号}
RTSP: rtsp://{ip}:{port}/stream_{通道号}
2.3.3、关闭静态流地址播放
livenvr.ini ->[base_config]->allow_stream_start_by_url=0 ， 默认是开启此功能的，配置后重启LiveNVR服务
[base_config]
allow_stream_start_by_url=0
支持 Windows Linux 及其它CPU架构（国产、嵌入式...）操作系统
安装包下载WEB：www.liveqing.com
